Product features:
1. This series of air conditioners adopts aluminized zinc plate/stainless steel plate as frame and panel material, which has strong corrosion resistance, beautiful appearance and good visual effect.
2. no welding design all parts assembly process does not use welding process, does not damage the unit itself sheet metal anti-corrosion coating, and convenient disassembly and assembly.
3. modular design adopts modular design concept, each functional section is relatively independent, maintenance operation is very convenient, and the degree of serialization is high, the design is simple and fast, improve the efficiency of supply.
4. the whole fresh air design adopts the whole fresh air design, the air conditioner into the air conditioning area for processing and filtering the whole fresh air, can greatly improve the air quality of the air conditioning area.
5. the design of heat recovery Ordinary full fresh air unit is the return air in air conditioning area directly discharge, with fresh air from outside state directly into the air, so more energy is needed to meet demand and the type of air conditioner heat recovery wheel adopts high performance silica gel/molecular sieve to recycle cooling capacity in the return air will be fresh air pretreatment, reduce the power consumption of the refrigeration unit.
6. Variable air volume design can be designed in the form of variable air volume. For the air conditioning area with variable air volume adjustment, the air supply volume can be automatically adjusted, and the operation under low load is more energy saving.
7. drawer design all functional modules are installed in the form of drawers, that is, all functional sections can be pulled out like drawer maintenance, maintenance is very convenient.
8. the exhaust water external design of the conventional air conditioner will be the exhaust water device installed in the table cold plate tube inside the unit, the exhaust water is very inconvenient, the air conditioner will be installed outside the exhaust water device, easy to operate.
9. the new sealing design for the hinged panel, the hollow rubber sealing ring and the panel into one design mode, to ensure that there is no air leakage in the door plate, compared with the conventional sealing strip sealing effect is better.
Basic parameters：
Cooling capacity:20~1000kW
Air flow:2000~20000m /h3
Air pressure : 200~2000Pa
Heat recovery method of wheel : silicone or molecular sieve wheel
Heat recovery rate can reach 70%
Application：
